PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery

A 16.07kWh 51.2V LiFePO4 battery with 314Ah cells and a 150A rating, sized for larger homes and small commercial backup.

Request quotationRequest datasheet
PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery
16.07kWhCapacity
51.2VVoltage
150AMax current
IP54Protection
PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery
PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery view 2PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery view 3PowerFly HZEB-LCT-16 16.07kWh Wall-Mounted Battery view 4

Technical data

Core specifications

Nominal energy16.07kWh
Usable energy14.47kWh at 90% DOD
Battery chemistryLiFePO4
Configuration3.2V 314Ah, 1P16S
Nominal voltage51.2V (44.8-57.6V)
Max charge/discharge current150A
Cycle life>=8,000 cycles at 90% DOD (25 C)
Warranty5+5 years
CommunicationCAN / RS485
Parallel capabilityUp to 15 units
InstallationWall-mounted or ground-mounted
Ingress protectionIP54
Operating temperatureCharge 0-55 C, discharge -20-55 C
Dimensions460 x 245 x 800mm
Weight127kg

Applications

Suitable project scenarios

Larger homesSmall commercial backupOff-grid cabinsRetrofit with an existing low-voltage inverter

Documentation

Documents supplied with this platform

Datasheet, certificate package, wiring diagram, and warranty card are issued against the confirmed order configuration.

Certification applicability depends on model, order configuration, and destination market. The latest matching certificate package is confirmed before final quotation.

FAQ

Common questions

What can a 150A battery actually run?

150A at 51.2V is 7.68kW at nominal voltage, so it carries a 6kW inverter with margin; at the 44.8V low end the same current gives 6.72kW.

How does it compare with the 10.54kWh model?

Same platform and cabinet family, but 314Ah cells instead of 206Ah and a 150A rating instead of 100A, so it carries a larger inverter as well as more energy.

Can it be installed outdoors?

It is IP54 and rated for wall or ground mounting, and the datasheet claims resistance to 200mm of continuous rain. Siting still matters: keep it off a flood path and within the 0-55 C charging window.

Project support

Need a configured battery storage solution?

Send your application, location, load profile, and target capacity. We will recommend a suitable Ruibit / Dawnice system and confirm sizing assumptions with you.

Quotation target: 24 working hours for a complete brief. Datasheet and certificate package supplied per configuration.
